BG-EXH-100C5
The BG-EXH-100C5 is an 18Gbps HDMI HDBaseT extender that transmits high-definition audio / video, RS-232, bi-directional IR, and internet signals to a distance of up to 328ft (100m) between the transmitter and receiver using a single CAT6/6a cable. Featuring video resolutions up to 4K@60Hz 4:4:4 and HDR, HDR10+, Dolby Vision, and HLG ensure the best image possible.
The integrated bi-directional IR pass-through allows for source and display control from either end of the system. The BG-EXH-100C5 transmitter and receiver are also capable of power over cable (PoC) meaning only one unit in the pair needs a power supply. Each unit also has a LAN port to further eliminate the need for extra cable runs. The system supports ARC and various audio formats such as Dolby Digital, Dolby TrueHD, LPCM, and many more as well as local audio extraction. This set of robust features in such a compact design makes for easy, flexible, and high quality installation options.
Features
- Audio Embedding Embed audio through S/PDIF optical
- Bi-Directional IR Control devices via IR either from the receiver or transmitter
- Compliant HDCP 2.2 supported to ensure content protection
- Long Range Utilizing HDBaseT technology to send uncompressed 4K signal up to 328ft (100m)
- Stunning Image Quality Crystal clear images at 4K 60Hz 4:4:4
- Power Over Cable Power only needs to be supplied to the either transmitter or receiver allowing for easier installation
- 3.5mm mini stereo audio output on receiver
- Rich Colors with HDR, HDR10+, Dolby Vision, HLG
- ARC and audio de-embedding through S/PDIF optical port on receiver
