BG-DA-14

The BG-DA-14 is a 4K HDMI 2.0 1x4 splitter. Supporting resolutions up to 4K2K@60Hz (4:4:4), this device simultaneously routes one HDMI source to four HDMI displays at speeds up to 18Gbps. This HDCP2.2 compliant unit also supports 3D video formats up to 4K2K@30Hz as well as high resolution VESA mode video formats up to QSXGA@60Hz. The smart EDID control eliminates any potential connectivity issues.

Supporting multi-channel audio formats including LPCM 7.1CH, Dolby TrueHD and DTS Master Audio, this device can be connected to an audio amplifier or A/V receiver for amazing sound quality.

Features

• 4K Supports resolutions up to 4K2K@60Hz 4:4:4
• Multi-channel audio support Supports LPCM 7.1CH, Dolby TrueHD, DTS-HD
• Smart EDID Eliminates connectivity issues
• Compact Design Easily installed in tight spaces
• Hi-Speed 18Gbps transfer rate
• Multiple Outputs Supports up to 4 displays

• HDMI 2.0b, HDCP 2.2 compliant
• Supports 3D video formats up to 4K2K@30Hz
• Supports high resolution VESA mode video format up to QSXGA@60Hz
